Encrypting Secrets with SOPs

·806 words·4 mins
Table of Contents

Secret Management with SOPs
#

With my kubernetes homelab infrastructure as code being public, secrets need to be encrypted if they are going to be stored as code. By default secrets are just encoded in base64 which can be decoded by anyone.

A way to resolve this is by using SOPs with flux CD. SOPs is an editor of encrypted files that supports YAML, JSON, ENV, INI and BINARY formats and can encrypt with AWS KMS, GCP KMS, Azure Key Vault, HuaweiCloud KMS and age.

The simplest encryption method to manage secrets at the moment is age, which is a simple, modern and secure file encryption tool. I will consider testing Azure Key Vault in the future.

paru -S age sops gnupg
age-keygen -o age.agekey
cat age.agekey

Example of “age.agekey” file

# created: 2026-01-19T17:44:04Z
# public key: age1zd5n9zx0dsdwdggjuvz32ppngn45gk0sdadasdasdsadasdsadaddadada
AGE-SECRET-929VUUUSHGHFEHSJHFHFRHFHJDSHSJHHFHHHFHFHFHFJEUYHAKJFSAE374HH646GC

Export public key as environmental

export AGE_PUBLIC=age1zd5n9zx0dsdwdggjuvz32ppngn45gk0sdadasdasdsadasdsadaddadada

Creating a test secret

kubectl create secret generic test-secret
\--from-literal=user=lancelot
\--from-literal=password=password123
\--dry-run=client
\-o yaml > test-secret.yaml

Encrypting test secret

sops --age=$AGE_PUBLIC
\--encrypt --encrypted-regex '^(data|stringData)$'
\--in-place test-secret.yaml
Encrypted output of test-secret.yaml
apiVersion: v1
data:
    password: ENC[AES256_GCM,data:6wPB1gnVImU=,iv:rUwG2uzF2Kc7jGvLJQyLPYrw3BwHN+HFw57GbTz8Bsg=,tag:IaKJqImzr8VCO8/CZFXPQw==,type:str]
    user: ENC[AES256_GCM,data:XhlBhK+l7Js=,iv:CKB5oUFexGTFnO9MkBt+UgYZk9/25cHyrMtQmxeKDE0=,tag:oqAFZ4Ict0Hkjs3Los4k4w==,type:str]
kind: Secret
metadata:
    name: test-secret
sops:
    age:
        - recipient: age1zd5n9zx0dsdwdggjuvz32ppngn45gk0sdadasdasdsadasdsadaddadada
          enc: |
            -----BEGIN AGE ENCRYPTED FILE-----
            YWdlLWVuY3J5cHRpb24ub3JnL3YxCi0+IFgyNTUxOSBUNndRdW40dHFZWUhHcVZN
            VjJta0F1MkYydHlVbVozRkRkZk1lTjJiWWdBCndrK2lHQ3F3Wm5mTnF0dG4yMUlI
            bWJvbnJYdGI4ZHRTUGFwdHFPSjFEeDgKLS0tIHNkUlcvQXRPOHJhRERCMlhQUTJP
            ZkovekVtaFM1SVR6NG0wU2k2c2JLbUkKGeAB+pFV8cNC7p7mvpboZ9EITbJAX6lJ
            c2U4fOEoYqzfW0Nsaym4iJ3U3MWyEW5vawkAvSAom/B2SaGQChVuzw==
            -----END AGE ENCRYPTED FILE-----
    lastmodified: "2026-01-19T20:47:25Z"
    mac: ENC[AES256_GCM,data:j4s84sBgCdIDxK0EIwC/Kp5GPRG5Cg8JCmamH79w+oVYvecI5tPUh/Ma8VuuqOsZyWekSQkbgqkpkg9y8CSbKKa2IUBrK/4oVV65vBPumrAQ0Mu8H1XOJe0qpQN123rntlYzuiJvl9GlTlH1C42p7MgkYNGNq/Lgi4gt87Rar3I=,iv:88gHPMv66kXDnIyzPtoH4EhNwFtBYwIhsD0B4ND+cgQ=,tag:JNr2LNM1Zvd5OmxA3KrxSA==,type:str]
    encrypted_regex: ^(data|stringData)$
    version: 3.11.0

Add the private key to the cluster

cat age.agekey | kubectl create secret generic sops-age --namespace=flux-system --from-file=age.agekey=/dev/stdin

Added sops as a decryption provider to apps.yaml kustomization file with the sops-age created above as a secretRef

apiVersion: kustomize.toolkit.fluxcd.io/v1
kind: Kustomization
metadata:
  name:  apps
  namespace: flux-system
spec:
  interval: 1m
  retryInterval: 1m
  timeout: 5m
  sourceRef:
    kind: GitRepository
    name: flux-system
  path: ./apps/staging
  prune: true

  decryption:
    provider: sops
    secretRef:
      name: sops-age

Created .sop.yaml at root of homelab directory. simplifies encrypting and decrypting files

creation_rules:
  - path_regex: \.yaml$
    encrypted_regex: ^(data|stringData)$
    age: age1zd5n9zx0dsdwdggjuvz32ppngn45gk0sdadasdasdsadasdsadaddadadal

Note - Had to export the whole file instead of just the public key for encrypt/decrypt to work

export SOPS_AGE_KEY_FILE=$HOME/.sops/age.agekey

Application Examples
#

Examples of applications on the repo with encrypted secrets.

Cloudflare Tunnels
#

Encrypting cloudflare credentials for tunnel with SOPs + age

kubectl create secret generic tunnel-credentials
\--from-file=credentials.json=59c97568-9eda-4dbf-9857-b6cf9cf91259.json
\--dry-run=client -o yaml > cloudflare-secret.yaml
\sops --encrypt --in-place cloudflare-secret.yaml

Linkding Environmental Variables
#

I previously used the command below inside linkding’s shell to config a user account. But this isn’t very GitOps friendly.

python manage.py createsuperuser --username=test --email=linkding-test@example.com

Linkding has a list of available environmental variables to declare:

  • LD_SUPERUSER_NAME - Admin Account
  • LD_SUPERUSER_PASSWORD - Admin Account Password
    These variables need to be declared in deployment.yaml but can’t be hard coded for obvious reason. Workflow: Create secret > Encrypt Secret with SOPS + age > Commit to Git > Secret Decrypted by FLUX via SOPS using “sop-age” secret in apps.yaml
kubectl create secret generic linkding-container-env
\--from-literal=LD_SUPERUSER_NAME=superadmin
\--from-literal=LD_SUPERUSER_PASSWORD=password123?
\--dry-run=client
\-o yaml > linkding-container-env-secret.yaml
sops --age=$AGE_PUBLIC \--encrypt --encrypted-regex '^(data|stringData)$' --in-place linkding-container-env-secret.yaml

To make these environmental variable available inside linkding, we’ll need to make use of envFrom.
envFrom allows you to set environment variables for a container by referencing either a ConfigMap or a Secret. When you use envFrom, all the key-value pairs in the referenced ConfigMap or Secret are set as environment variables for the container.

      containers:
      - image: ghcr.io/sissbruecker/linkding:1.44.2-plus-alpine
        name: linkding
        envFrom:
         # - configMapRef:
         #     name: linkding-configmap
          - secretRef:
              name: linkding-container-env

Added linkding-container-env-secret.yaml to apps/staging and referenced it in linkding kustomization

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
namespace: linkding
resources:
	- ../../base/linkding/
	- cloudflare.yaml
	- cloudflare-secret.yaml
	- linkding-container-env-secret.yaml

Note - Linkding needs to be restarted for ENV variables to be injected, this can be done by commenting out directory and resource references in the base and staging kustomization files. Note - It is preferable to use ENV variables for configuration if possible.

Grafana Dashboard with self signed TLS cert
#

Generating TLS cert with openssl https://www.digitalocean.com/community/tutorials/openssl-essentials-working-with-ssl-certificates-private-keys-and-csrs NOTE

openssl req -x509 -nodes -days 365 -newkey rsa:2048 \
  -keyout ./tls.key \
  -out ./tls.crt \
  -subj "/C=UK/ST=London/L=Basement/O=Homelab/OU=Monitoring/CN=grfs.ksefuke-labs.com" \
  -addext "subjectAltName=DNS:grfs.ksefuke-labs.com"

Creating TLS secret

kubectl create secret tls grafana-tls-secret \
  --cert=tls.crt \
  --key=tls.key \
  --namespace=monitoring \
  --dry-run=client \
  -o yaml > grafana-tls-secret.yaml
Application of Secret in Grafana's helm release manifest
apiVersion: helm.toolkit.fluxcd.io/v2
kind: HelmRelease
metadata:
  name: kube-prometheus-stack
  namespace: monitoring
spec:
  interval: 30m
  chart:
    spec:
      chart: kube-prometheus-stack
      version: "66.2.2"
      sourceRef:
        kind: HelmRepository
        name: kube-prometheus-stack
        namespace: monitoring
      interval: 12h
  install:
    crds: Create
  upgrade:
    crds: CreateReplace
  driftDetection:
    mode: enabled
    ignore:
      # Ignore "validated" annotation which is not inserted during install
      - paths: ["/metadata/annotations/prometheus-operator-validated"]
        target:
          kind: PrometheusRule
  values:
    grafana:
      ingress:
        enabled: true
        ingressClassName: traefik
      #annotations: {} - Potentially needed by cert manager
      # kubernetes.io/ingress.class: nginx
      # kubernetes.io/tls-acme: "true"

      ## Hostnames.Must be provided if Ingress is enable.
        hosts:
          - grfs.ksefuke-labs.com

      ## TLS configuration for grafana Ingress
      ## Secret must be manually created in the namespace
        tls:
          - secretName: grafana-tls-secret
            hosts:
              - grfs.ksefuke-labs.com
